Applications
Multi-purpose hose, with very good ageing. Suitable for air, cold and hot water.
Also suitable for pressure service line for ester, ketone, alcohol based paints and numerous chemicals.
Advantages
- Hose cover resistant to splashing of corrosive chemicals.
- Free from silicone.
- Hose remains flexible within a wide temperature range.
- Conductive tube and cover.
Design
Overview
Inner tube
EPDM, black, smooth.
Reinforcement
synthetic textile
Cover
EPDM, black, smooth.
Temperature range
-30 to +100
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
¤ Upon availability. * Tolerance on length: ± 1 % (ISO 1307 Standard)
