Overview
Features
High grade halogenated butyl.
Applications
Gaskets or washers cutting and manufacturing of pieces for general industrial purpose applications in contact with:
- maximum temperature +140°C: water, steam
- maximum temperature +80°C: sea water, swimming pool water, water washing
- maximum temperature 20°C: sulphuric acid (concentration ≤95%), nitric acid (concentration ≤50%)
- maximum temperature 70°C: hydrochloric acid (concentration ≤37%)
- maximum temperature 80°C: lime, potash, soda (concentration ≤100°C)
Advantages
Good resistance to diluted acids and bases
Excellent ageing resistance
Excellent ozone resistance
Excellent low and high temperature resistance
Good abrasion resistance and compression set values
Low air permeability
Excellent impermeability to gases
Resistant to most inorganic substances
High resistance to mineral acids and alkalis
Resistant to ketones and low molecular weight alcohols
Matte finish to guarantee a good surface finished quality and to secure an easy unrolling.
Benefits
Performance
Reliability
Safety
Service life
Mechanical, Physical and Chemical Properties
Mechanical
Measure characteristic Standard Value
Density 1.27 ± 0.05 g/cm³
Hardness ASTM D2240 60 ± 5 Shore A
Tensile strength ISO 37 ≥8 MPa
Elongation at break ISO 37 ≥400 %
Compression set after 22h at 70°C ISO 815-1 ≤25 %
Temperature
Measure characteristic Standard Value
Working temperature -40/+130 °C
Ageing
Measure characteristic Standard Value
∆ Hardness after 168h at 70°C ASTM D573 ≤5 Shore A
∆ Tensile strength after 168h at 70°C ASTM D573 ≤-15 %
∆ Elongation at break after 168h at 70°C ASTM D573 ≤-40 %
Ozone resistance, 100pphm, 48h, 38°C, 20% ASTM D1149 type A No crack %
Oil Resistance
Measure characteristic Standard Value
Chemical Resistance
Diluted acids and bases Concentrated acids and bases Ozone Oils and hydrocarbons
Very good Good Very good Non suitable
Dimensions
