Applications
Used for pumping fish in fish farms and fish processing factories.
2 levels of working pressure available :
- 2 bar
- 3 bar
Advantages
- Flexible hose design providing optimum characteristics for this application.
- Withstands rough handling.
- Without helix for discharge applications.
Design
Technical drawing
Overview
Inner tube
wear resistant SBR/NBR, black, smooth.
Reinforcement
synthetic textile
Cover
weather resistant SBR/NBR, black, fabric impression.
Temperature range
-40 to +80
Additional information
Other lengths available on request.
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
254 |
263.0 |
3 |
10 | 40 | 2955660 | |||
254 |
265.0 |
3 |
10 | 40 | 2863290 | |||
305 |
312.0 |
3 |
10 | 40 | 2861070 | |||
305 |
314.0 |
3 |
10 | 40 | 2913530 | |||
305 |
316.0 |
3 |
10 | 40 | 2911310 | |||
355 |
362.0 |
3 |
10 | 40 | 2860840 | |||
355 |
364.0 |
3 |
10 | 20 | 1300190 | |||
355 |
364.0 |
3 |
10 | 40 | 2052650 | |||
355 |
366.0 |
3 |
10 | 291.880 | 40.00 | 5500653 |
¤ Upon availability.
* Tolerance on length: ± 1 % (ISO 1307 Standard)
* Tolerance on length: ± 1 % (ISO 1307 Standard)
