Applications

Suction and delivery hose to transfer abrasive material such as cement, sand, etc.

Design

Overview
Inner tube
natural rubber, black, smooth.
Reinforcement
synthetic textile, embedded steel helix and antistatic wire
Cover
synthetic SBR rubber, black, fabric impression.
Temperature range
-30 to +80
Technical Specifications
ID (mm) OD (mm) Working Pressure (bar) Bursting pressure (bar) Max. vacuum (bar) Bending radius (mm) Weight (kg/m) Length (m) Article number
102
126
10
 30 0.9 410 5.9 40 5513677
127
153
10
 30 0.9 510 352.000 40.00 5513678
152
178
10
 30 0.9 610 416.000 40.00 5513679
76
98
10
 30 0.9 320 4.1 40 5513675
90
108
10
 30 0.9 360 4.18 40 5513676
¤ Upon availability.
* Tolerance on length: ± 1 % (ISO 1307 Standard)
