PETROVAST

Applications

For heavy duty industrial cleaning and circulation of saturated and superheated steam in heating systems. Used in the petrochemical, building, shipyard and chemical industry.

Advantages

- Multipurpose hose. - Highly flexible. - Very high temperature resistance. - Chemical resistant. - Durable and safe performance. - Fulfills international standards.

Overview

Inner tube

EPDM, black, smooth.

Reinforcement

brasscoated steel

Cover

EPDM, black, fabric impression.

Additional information

Other lengths and dimensions available on request.

Technical Specifications

ID (mm)	OD (mm)	Working Pressure (bar)	Bursting pressure (bar)	Max. vacuum (bar)	Bending radius (mm)	Weight (kg/m)	Length (m)	Article number
13.0	25.0		180		130	10.220	20.00	5014992
13.0	25.0		180		130	20.440	40.00	5014993
16.0	30.0		180		160	13.760	20.00	5014994
16.0	30.0		180		160	27.520	40.00	5014995
19.0	33.0		180		190	11.865	15.00	5014982
19.0	33.0		180		190	15.820	20.00	5014983
19.0	33.0		180		190	31.640	40.00	5014984
19.0	33.0		180		190	47.460	60.00	5014985
25	40.0		180		250	16.065	15.00	5014986
25	40.0		180		250	21.420	20.00	5014987
25	40.0		180		250	42.840	40.00	5014988
25	40.0		180		250	64.260	60.00	5014989
32	48.0		180		320	28.400	20.00	5014996
32	48.0		180		320	56.800	40.00	5014997
38	54.0		180		380	33.280	20.00	5014998
51	69.0		180		500	47.980	20.00	5014999
51	69.0		180		500	95.960	40.00	5513540
9.5	21.5		180		120	8.500	20.00	5014990
9.5	21.5		180		120	17.000	40.00	5014991
