Applications
Low pressure steam hose.
Advantages
- Highly flexible.
- Resistant to abrasion.
Design
Overview
Inner tube
synthetic EPDM rubber, black, smooth.
Reinforcement
synthetic textile
Cover
synthetic EPDM rubber, black, fabric impression.
Temperature range
-30 to +164
Additional information
Other lengths on request
Technical Specifications
| ID (mm) | OD (mm) | Working Pressure (bar) | Bursting pressure (bar) | Max. vacuum (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number |
19.0 |
33 |
6 |
60 | 190 | 0.69 | 40 | 5513647 | |
25 |
40 |
6 |
60 | 250 | 0.96 | 40 | 5513648 | |
32 |
48 |
6 |
60 | 320 | 50.400 | 40.00 | 5513649 | |
38 |
54 |
6 |
60 | 380 | 58.000 | 40.00 | 5513650 | |
51 |
69 |
6 |
60 | 500 | 1.86 | 40 | 5513651 |
¤ Upon availability.
* Tolerance on length: ± 1 % (ISO 1307 Standard)
* Tolerance on length: ± 1 % (ISO 1307 Standard)
